IP Camera

IPC335

• SONY IMX335LQN-C STARVIS: Designed for high-definition daytime image quality and strong low-light performance at night.
• Sensor: 6MP 1/2.8” low-light CMOS sensor; color: 0.0001 Lux @ F1.2; black-and-white: 0.0001 Lux @ F1.2
• Video Processing: Advanced H.265+ encoding (compatible with H.265/H.264), dual-stream output, AVI format; adjustable bitrate from 0.1 Mbps to 8 Mbps; adjustable frame rate from 1 to 30 fps
• Video Output: Main stream: 6MP 3072 × 2048 @ 20 fps, 5MP 2880 × 1616 @ 25 fps, 4MP 2560 × 1440 @ 25 fps, 2MP 1920 × 1080 @ 25 fps; Sub-stream: 800 × 448 @ 25 fps
• Network Interface: One RJ45 Ethernet port, 10/100 Mbps adaptive; supports RTSP, FTP, DHCP, NTP, UPnP, and other network protocols
• Protocol Support: ONVIF compliant for integration with third-party back-end systems and platforms
• Power Supply: Supports PoE

IPC415

• SONY IMX415 STARVIS: Designed for ultra-high-definition imaging with excellent low-light performance, making it suitable for intelligent monitoring applications that require both image clarity and reliability.
• Sensor: 8MP 1/2.8” CMOS sensor, SONY IMX415
• Video Processing: Advanced H.265+/H.265/H.264 video encoding; adjustable bitrate from 0.1 Mbps to 12 Mbps; adjustable frame rate from 1 to 20 fps
• Video Output: Main stream: 3840 × 2160 @ 20 fps; 3072 × 2048, 2592 × 1944, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720 @ 30 fps; Sub-stream: 720 × 480, D1, VGA, 640 × 360
• IRCUT: Built-in IRCUT switching circuit, supporting automatic external control and manual timing control for day/night mode switching
• Network Interface: One RJ45 Ethernet port, 10/100 Mbps adaptive
• Light Board Interface: Supports CDS, PWM infrared, and PWM warm light
• Protection Design: Power supply and network interfaces are equipped with full lightning protection, compliant with GB/T 17626.5 and IEC 61000-4-5 standards
• Smart Functions: Supports OSD, real-time audio and video transmission, human detection, dual-light alarm, and voice alarm
• Network Protocols: Supports HTTP, RTSP, DHCP, NTP, ONVIF, and P2P; optional support for GB28181, RTMP, and compatibility with multiple NVR platforms
• Mobile Monitoring: Supports mobile monitoring on iOS and Android via Danale
• Operating Environment: -40°C to +85°C
